ATO High Torque Nema 23 Stepper Motor, 3A/ 4A, 1.8 Degree, 2 Phase 4 Wires, for CNC Mill Lathe Router (Holding Torque 2.5Nm)
Product details
| Management number | 233294231 | Release Date | 2026/06/27 | List Price | US$58.32 | Model Number | 233294231 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specification : Electrical Specification:Step Angle 1.8°HoldingTorque 2.2Nm/2.5Nm/1.89NmRatedCurrent/phase 3.0A/4.0A/2.8APhaseResistance 1.2Ω/1.6Ω/1.13ΩInductance 4mH/6.8mH/3.6mHRotorInertia 600g-cm2/800g-cm2/440g-cm2FrameSize 57 x 57mmPhysical Specification: Length 82mm/98mm/76mm ShaftDiameter Φ6.35mm ShaftLength 19mm MotorLeads 4 Weight 1.2kg/1.4kg/1.1kg StepAngle Accuracy ±5% (full step, noload)Technical Parameters: Resistance Accuracy ±10% InductanceAccuracy ±20% TemperatureRise 80℃ Max. (ratedcurrent, 2 phase on) AmbientTemperature -20℃~+50℃ InsulationResistance 100MΩ Min. 500VDC DielectricStrength 500V AC for one minute ShaftRadial Play 0.02Max. 450g ShaftAxial Play 0.08Max. 450gQuality Assurance:Warranty Period 12 monthsCertificate CE, ROHs, ISO/SGS9001
- Rated Current/phase3.0A/4.0A/2.8A
- Holding Torque2.2Nm/2.5Nm/1.89Nm, Optional
- Warranty Period 12 months,with CE, ROHs, ISO/SGS9001 Certificate
- Application: CNC Router Engraving Milling/3D Printer, Lazer, Textile machine
- If you are not sure about the size or have any issue about the product or service, please don't hesitate to email us. We will answer you within 12h
| UPC | 783902769441 |
|---|---|
| ASIN | B08BNH2KV8 |
| Voltage | 500 Volts |
| Brand Name | ATO |
| Model Name | phase 4 |
| Manufacturer | ATO |
| Material Type | Copper |
